三相三线制: 220/380/460V±10%, 50/60Hz±5%

单相两线制: 220V±10%, 50/60Hz±5%(24VC)

输入信号: DC 4-20mA; Passive dry contact; Field bus (input signal
manufactured according to requirements)

输出信号: DC 4-20mA; Four sets of field configurable bistable output contacts;
1 set of remote pointing monostable output contacts 1 set of fault warning
monostable contacts. (Output signals are manufactured according to requirements)

输出电流负载阻抗:<750Ω

环境温度: -30-70°C (ultra-low temperature and high temperature
manufacturing according to requirements)

防护等级: IP55, IP65, IP67 (Manufacture IP68 according to requirements)

防爆等级: ExdIIBT4, ExdIICT4

回差: ≤±0.5%

基本误差: ±0.5%

灵敏度: 0.3-3 continuous adjustable and controllable.
